Product Specifications Product Classification Brand HELIAX Product Type Wireless and radiating connector General Specifications Interface N Male Body Style Straight Brand HELIAX Mounting Angle Straight Electrical Specifications Connector Impedance 50 ohm Operating Frequency Band 0 – 6000 MHz Cable Impedance 50 ohm 3rd Order IMD, typical -112 dBm @ 910 MHz 3rd Order IMD Test Method Two +43 dBm carriers RF Operating Voltage, maximum (vrms) 707.00 V dc Test Voltage 2500 V Outer Contact Resistance, maximum 0.25 mOhm Inner Contact Resistance, maximum 1.00 mOhm Insulation Resistance, minimum 5000 MOhm Average Power 0.7 kW @ 900 MHz Peak Power, maximum 10.00 kW Shielding Effectiveness -110 dB Outline Drawing Click on image below to enlarge. Mechanical Specifications Outer Contact Attachment Method Self-flare Inner Contact Attachment Method Solder Outer Contact Plating Copper alloy treatment Inner Contact Plating Copper alloy treatment Interface Durability 500 cycles Interface Durability Method IEC 61169-4:17 Connector Retention Tensile Force 670 N | 151 lbf Connector Retention Torque 2.70 N-m | 1.99 ft lb Insertion Force 124.55 N | 28.00 lbf Insertion Force Method IEC 61169-16:9.3.5 Pressurizable No Coupling Nut Proof Torque 1.70 N-m | 1.25 ft lb Coupling Nut Proof Torque Method IEC 61169-16:9.3.11 Coupling Nut Retention Force 445.00 N | 100.04 lbf Coupling Nut Retention Force Method IEC 61169-16:9.3.11 Dimensions Nominal Size 3/8 in Diameter 17.55 mm | 0.69 in Length 57.57 mm | 2.27 in Weight 47.50 g | 0.10 lb Environmental Specifications Operating Temperature -55 C to +85 C (-67 F to +185 F) Storage Temperature -65 C to +125 C (-85 F to +257 F) Immersion Depth 1 m Immersion Test Mating Mated Immersion Test Method IEC 60529:2001, IP68 Moisture Resistance Test Method IEC 60068-2-3 Mechanical Shock Test Method IEC 60068-2-27 Thermal Shock Test Method IEC 60068-2-14 Vibration Test Method IEC 60068-2-6 Corrosion Test Method IEC 60068-2-11 Standard Conditions Attenuation, Ambient Temperature 20 C | 68 F Average Power, Ambient Temperature 40 C | 104 F Average Power, Inner Conductor Temperature 100 C | 212 F . . Due to recent problems with mailing to the UK. All UK buyers should contact us before buying. Thank you . We are sorry for this problem not coming from us.
