Festo Solenoid Valve MFH-5-1/4-B Primary brand Festo Main function Valve (Electrically actuated) Product series / family nameElectrically actuated valves - Universal directional control valves - Tiger 2000 Sub-range name MFH-B series (Tiger 2000) Functions Electrically-actuated single solenoid pneumatic piloted control valve Valve function 5/2-way 5-ports 2-positions Mechanical spring reset Monostable Design B-series non-detenting manual override Poppet valve internal pilot air non-revers. flow soft sealing Compressed air (-10C...+60C) in accordance with ISO 8573-1/2010 [7;4;4] as input medium Flow1300L/min (LPM) Pressure +2...+10bar operating pressure Connection type Electrical connection via MSF coil 5 x G1/4" threaded (female) pneumatic connections (ports 1; 2; 3; 4; 5) Mounting mode Through-hole Net Width (mm) 32 mm Material Die-cast Aluminium housing NBR/TPE-U(PU) seals Ambient air temperature for operation-5...+40 C Chemical resistanceCorrosion resistance class CRC 1 (low corrosion stress) Order code / Manufacturer SKU15901 Manufacturer product status Commercialized Equivalent to MFH514B Compliant with standard(s)RoHS New One Year Warranty
