Extra-Duty Plastic In-Use Weatherproof Cover, Single-Gang, Vrt/Hrz, 3.625" Clear Model#WP5110C Plastic In-Use Weatherproof Covers are extra-duty rated and easy to install. Covers come with a gasket, mounting screws, base, cover assembly and inserts to meet the needs of a variety of applications. Complies with 2020 NEC Article 406.9 (B)(1) for wet locations and extra-duty applications CEC Article 26-702 Compliant UL Certified for Type 3R outdoor enclosures Meets requirements for cold impact testing: -60 F (-51 C) Heavy-duty UV stabilized polycarbonate cover, mounting base and inserts 1?8" (3 mm) thick, neoprene gasket with slits for mounting screws Lockable hasp: All models accept up to 1?4" (6 mm) dia shank Impact rated: 12 lbf. impact test to ensure cover remains intact Reinforced hinge pin designed to exceed 40 lbf. hinge hang/stress test Box Type Single Is Extra-Duty Rated Yes Color Clear, Gray Hinge Direction Vertical/Horizontal Accepted Cord Size Max 1x12 AWG, 2x14 AWG CA Prop 65 Message This product is in compliance with Prop65 California Proposition 65 None Country of Origin (Intermatic) MEXICO Cover Gasket 3mm Enclosure Type Outdoor type 3R plastic Has Reinforced Hinge Pin Yes Insert Types Included WP17 Material UV Stabilized Polycarbonate RoHS Certification X UL Certification cULus Warranty Period 1-Year limited Weatherproof Cover Material UV Stabilized Plastic Lockable Hasp Maximum Diameter (in) 1/4 Lockable Hasp Maximum Diameter (mm) 6 Product Depth (in) 3.625 Product Depth (mm) 92 Product Height (in) 6.33 Product Height (mm) 160.3 Product Width (in) 4.66 Product Width (mm) 119.1 Unit Carton Height (in) 6.5 Unit Carton Length (in) 4.75 Unit Carton Weight (lb) 0.65 Unit Carton Width (in) 2.75 Units Per Pallet 720
