US-16x08 16-IN/8-OUT USB Audio/MIDI Interface The TASCAM US-16x08 captures 16 mic and line inputs to your computer with clear sound quality and advanced features to manage big sessions. Eight Ultra-HDDA microphone preamps deliver the cleanest and quietest operation in their class, while delivering up to 56dB of gain. An additional eight line inputs are provided, two of them switchable to instrument level for direct guitar or bass recording. Eight balanced line outputs are also available, two with a level control on the front panel for monitoring. Sampling frequency : 44.1k/48k/88.2k/96k Hz THD : 0.008% or less S/N ratio : 100dB or more EIN : -125dBu or less Power : Dedicated AC adapter Power consumption : 12W Dimensions : 445(W)59(H)219(D)mm Weight : 2.8kg Ultra-HDDA (High Definition Discrete Architecture) mic preamps with ?125dBu EIN Eight Ultra-HDDA mic pres with XLR connectors, eight TRS inputs Standalone mode for use as an independent mic preamp Up to 96kHz/24-bit recording Connect with iPads and other iOS devices via Class Compliant drivers +48V phantom power available for all microphone inputs High-impedance inputs available 56 dB of preamp gain, ideal for dynamic or ribbon microphones ***MISSING*** AC adapter (GPE248-120200-Z) (with output plug A/B for replacement) USB cable Hex key Rack mount angle attachment screws 4 Owner?s Manual
